Product Description

S 210-AS Series Multinational Data Logger is designed and developed by our expert technocrats is ideal to be utilized for many applications such as Pharmaceutical, warehousing, scientific research institutes, electronic, transportation, textile, commercial buildings, professional laboratory fields and more. Easy to operate and maintain, it is made up of high grade polymer housing, Wide LED Display Screen, Soft touch keys and other required components that assure its high reliability, highest accuracy level and long lasting nature. We offer S 210-AS Series Multinational Data Logger at estimated rate of Rs. 18,000 / Number.

Features:

Various inputs: 4-20Ma/0-5V/0-10V etc
Patented structure technology, easy to install battery and portable
Compact design, desktop and wall-mounted
4-20mA data logger with 4-channel, it can measure and record 4-channel direct current signals (4-20mA) simultaneously

Specifications:

Measuring accuracy

/-0.2%FS
Resolution of voltage input	13 bits (8192 levels)
Resolution of current input	7900 levels
Signal character at binary input	Low potential-less contacts or the two-state voltage signal
Minimum pulse duration at binary input	500ms (shorter pulses may not be recorded)
Maximum frequency at binary input	0.5Hz (i.e. maximum 5 pulses for 10s)
Power current through contact at binary input	3 uA (contact closed)
Voltage open-circuit at binary input	Maximum 3.6V
Low voltage level at binary input	0 to 0.2V (maximum current from the input 3uA )
High voltage level at binary input	3.0 to 30V (maximum current to the input 100 nA)
Power	2*7# battery
Display	LCD display
Measuring range	50 square meters
Sampling interval	Adjustable from 2s to 24 hours according to requirements
Dimension	125mm28mm22mm
LCD size	18mm*13.5mm
Net weight	62g
Accessories	Software CD, inspection certificate, warranty card, operation manual, fixed holder and screws.
